ABB TRIO-7.5-TL-OUTD User Manual

- 20 -
000318CG
2 - Characteristics
Characteristics and technical data
Table: Technical Data TRIO-5.8-TL-OUTD TRIO-7.5-TL-OUTD TRIO-8.5-TL-OUTD
Input
Absolute Maximum Input Voltage (V
max,abs) 1000 V
Rated Input Voltage (V
dcr) 620 V
Input start-up voltage (V
start) 350 V (adj. 200...500 V)
Input operating interval (V
dcmin...Vdcmax) 0.7 x Vstart... 950 V
Input Nominal Power(P
dcr) 5950 Wp 7650 Wp 8700 W
Number of Independent MPPT 1 2 2
Maximum input power for Each MPPT (P
MPPT-
max
)
6050 W
Derating from
MAX to Zero
[800V≤VMPPT≤950V]
4800 W 4800 W
DC Voltage MPPT Interval
(V
MPPTmin...VMPPTmax) to Pacr
320…800 V
- -
Input voltage interval (V
MPPTmin ... VMPPTmax)
to Pacr (cong. MPPT parallel)
-
320…800 V 320…800 V
Power limiting vs. Input voltage (parallel MPPT
conguration)
-
Derating from
MAX to Zero
[800V≤VMPPT≤950V]
Derating from
MAX to Zero
[800V≤VMPPT≤950V]
DC Power limiting for each MPPT with Inde-
pendent MPPT Conguration to P
acr, maximum
unbalance example
-
4800 W
[320V≤VMPPT≤800V]
other channel:
Pdcr-4800W
[215V≤VMPPT≤800V]
4800 W
[320V≤VMPPT≤800V]
other channel:
Pdcr-4800W
[290V≤VMPPT≤800V]
Maximum DC Input Current (Idcmax) / for each
MPPT (IMPPTmax)
18.9 A 30 A / 15 A 30 A / 15 A
Maximum Return current (AC side vs DC side) Negligible
Number of DC Connection Pairs in Input for
each MPPT
2 (Version -S)
DC Input Connector type (components indicated
or equivalents)
Connector PV Tool Free WM / MC4
(Screw terminal block in Standard version)
Type of photovoltaic panels that can be con-
nected at input according to IEC 61730
Class A
Input protection
Reverse Polarity Protection Yes, from current limited source
Input Overvoltage protection for each MPPT -
Varistors
2 for each MPPT
Maximum short-circuit current for each MPPT 24.0 A 20.0 A 20.0 A
Insulation Check Complying with the local standard
Input-ground capacity that can be borne without
leakage protection
2.0uF
Characteristics of DC Disconnect Switch for
each MPPT (Version with DC disconnect switch)
16A /1000V 25A / 800V
Output
AC Connection to the grid Three-phase, 3 or 4 wires + PE
Nominal AC output voltage (V
acr) 400 V
Output voltage range (V
acmin...Vacmin) 320...480 V
(1)
Nominal AC Output Power (Pacr @cosφ=1) 5800 W 7500 W 8500 W
Maximum apparent Output power (S
max) 5800 VA 7500 VA 8500 VA
Maximum output current (I
acmax) 10.0 A 12.5 A 14.5 A
Contribution to short-circuit current 12.0 A 14.5 A 16.5 A
Inrush current Negligible
Maximum fault current <20Arms(100mS)
