Operating instruction manual | TX Thermal Disperson Level Switches 11
LIQUID FLOW (TOP BOARD)
JP11 Jumper Conguration
CONDITION State A State B
Relay Energized LED On Flow < Set-Point Flow > Set-Point
Relay De-energized LED OFF Flow > Set-Point Flow < Set-Point
LEVEL OR AIR FLOW (TOP BOARD)
JP11 Jumper Conguration
CONDITION State A State B
Relay Energized LED On DRY or
Air Flow < Set-Point
WET or
Air Flow > Set-Point
Relay De-energized LED OFF WET or
Air Flow > Set-Point
DRY or
Flow < Set-Point
LEVEL OR AIR FLOW (TOP BOARD)
JP11 Jumper Conguration
CONDITION State A State B
Relay Energized LED On Temperature > Set-Point Temperature < Set-Point
Relay De-energized LED OFF Temperature < Set-Point Temperature > Set-Point
4.1 Second Switchpoint Option Board (Top Board) (cont’d)
1
3
2
4
2
4
1
3
1
3
2
4
2
4
1
3
1
3
2
4
2
4
1
3
