ABB VICPAS CP660-x - Electromagnetic Compatibility (EMC)

Operating Instructions 8 CP650, CP660, CP675
Electromagnetic Compatibility (EMC)
Test executed on the 230 V AC side of the Power Supply (EN 61000-4-11).
Parameter
Value
According to
Emitted interference
Class A
EN 55011
Electrostatic
8 kV (air electrostatic discharge)
4 kV (contact electrostatic discharge)
EN 61000-4-2
Immunity to radiated radio-
frequency
80 MHz … 1 GHz, 10 V/m
1 GHz … 2 GHz, 3 V/m
2 GHz … 2.7 GHz, 1 V/m
EN 61000-4-3
Electromagnetic field
900 MHz, 10 V/m
EN V 50204
Immunity to conducted dis-
turbances inducted by radiof-
requency field
0.15 MHz … 80 MHz 10 V
EN 61000-4-3
Fast transient
2 KV power supply
1 KV signal lines
EN 61000-4-4
Input and output AC power
ports
Level: 2 kV (L1/L2-PE) 1 kV (L1-L2)
EN 61000-4-5
Signal port
Level: 1 kV (line to earth)
Immunity to conducted dis-
turbances inducted by radiof-
requency field
0.15 … 80 MHz, 10 V
EN 61000-4-6
Voltage dips, short interrup-
tions and voltage variations
immunity test
Port: AC mains.
Level: 0 % / duration: 1 cycle and 250 cycles (50 Hz) or
300 cycles (60 Hz);
40 % / duration: 10 cycles (50 Hz) or 12 cycles (60 Hz);
70 % / duration: 25 cycles (50 Hz) or 30 cycles (60 Hz);
Phase: 0°-180°
Electrostatic discharge
8 kV in air
EN 61000-4-2
PC/Printer Port – COM2
RS-232, RS-485, RS-422 software configurable
300 … 38400 baud
PLC Port – COM1
RS-232, RS-485, RS-422 software configurable
300 … 38400 baud
AUX Port
Connector DB-9 pin female (functionality can be config-
ured with an optional communication module)
User memory
Flash 128 Mb
Recipe memory
32 kB FRAM
Hardware clock
Clock/calendar with back-up battery
Accuracy RTC (at 25°C
operating)
< 100 ppm
