Operating Instructions 16 CP650, CP660, CP675
Ethernet Port
Ethernet Port
A
OFF: No activity
BLINKING: Activity
B
ON: Valid link hast NOT been detected
OFF: Valid link has been detected
Pin
Description
Pin
Description
Pin
Description
Pin
Description
1
TX OUT +
3
RX OUT +
5
7
2
TX OUT -
4
6
RX OUT -
