Abbott e i-STAT Alinity - Pathway Screen Anatomy

Buon 1
Buon 2
Buon 3
Buon 4
Buon 2 Buon 3Buon 1
Page Title
Home
Alerts
Idenficaon Tab
Acon
Tab 1
Message Area
SECTION 4
12
i-STAT Alinity — Quick Reference Guide Art: 731848-01 Rev K Rev. Date: 02-Apr-2021
SCREEN COMPONENTS AND THEIR MEANINGS (CONT.)
A generic pathway screen is shown in the example above.
Anatomy of a Pathway Screen
A
HEADER:
®
Identication Tab
¯
Displays details such as patient ID, cartridge name, liquid
quality control name
®
Header Action Tabs
¯
Provide options for screen navigation
B
PAGE TITLE
C
MESSAGE AREA
D
BODY:
®
Buttons in this area provide access to pathways , OR
®
Location of details such as data entry eld, help graphics,
selection options
E
SIDE ACTION TABS:
®
Provide access to area or action indicated
F
ALERT BUTTON:
®
Provides access to Alerts description
G
ACTION BUTTONS:
®
Provide options for screen navigation
A
B
D
F
G
C
E
