Charger Indicators
The charger has a power icon, a baery icon, and a paent controller alert icon as
shown in the gure below. The charger provides indicator lights and sounds that show
the charger status and the acon being performed.
▪ PC Alert icon. The PC alert icon illuminates when the charger has encountered an▪
error. You may view more informaon about the error on your paent controller.
▪
Power icon. The power icon illuminates when the charger is turned on. When the
▪
charger is charging the generator, the power icon blinks slowly. When the charger is
in pairing mode, the power icon blinks quickly.
▪
Baery icon. The baery icon illuminates in segments to indicate the charger
▪
baery level. While the charger is being charged, a segment of the baery icon
blinks.
NOTE: The indicator lights on the charger may be dicult to see if under direct
sunlight.
Figure 1. Charger icons
1. PC Alert icon1.
2. Power icon2.
3. Baery icon3.
Table 1. Charger sounds
Event Charger sound
Power on 1 beep
Volume on 1 beep
Power o 2 beeps
Error 3 beeps every 5 seconds
Low baery 3 beeps every 5 minutes
Generator found Short, repeang beeps
Generator charging started 2 beeps
low tone then high tone
Generator charging stopped
(not aligned)
2 beeps
high tone then low tone
Generator charging complete
(fully charged)
3 beeps
low tone, high tone, then low tone
