1-2 Chapter 1
12. Internal I/O Connectors
• 1x PCI Express x16 slot
• 3x PCI Express x1 slots
• 2x PCI slots
• 1x Floppy port supports up to 2.88MB
• 4x SATA 150 connectors
• 1x Ultra ATA/100/66/33 connector
• 2x USB 2.0 headers
• 2x IEEE 1394 headers (For AG8 only)
• 1x FP-Audio header
• 1x CD-IN header
• 1x AUX-IN header
13. Back Panel I/O
• 1x PS/2 Keyboard, 1x PS/2 mouse
• 1x Serial port, 1x Parallel port
• 1x S/PDIF In connector (For AG8 only)
• 1x S/PDIF Out connector (For AG8 only)
• 1x AUDIO1 connector (Rear-Left / Rear-Right, Center/Subwoofer)
• 1x AUDIO2 connector (Mic-In, Line-In, Front-Left/Front-Right)
• 2x USB 2.0 connectors, 1x IEEE 1394 connector (For AG8 only)
• 2x USB 2.0 connectors, 1x RJ-45 Gigabit LAN connector
14. Miscellaneous
• ATX form factor (305mm x 230mm)
Specifications and information contained herein are subject to change without notice.
