Hardware Setup
AN-M2/AN-M2HD 1-19
1.9 Onboard Indicators
1.9.1 Power Source Indicators
• 5VSB: This LED lights up when the power supply is connected with power source.
• VCC: This LED lights up when the system power is on.
