Hardware Setup
AN-M2/AN-M2HD 1-1
1. Hardware Setup
1.1 Specifications
1.1.1 AN-M2
CPU
• Supports Socket AM2 940 Processor
with 2000MT/s system bus using Hyper
Transport™ Technology
• Supports AMD CPU Cool ‘n’ Quiet
Technology
Chipset
• NVIDIA GeForce 7025 / nForce 630a
Memory
• 4x 240-pin DIMM slots support
maximum memory capacity up to 8GB
• Supports Dual Channel DDR2 800
Un-buffered ECC/Non-ECC memory
Graphics
• Integrated GeForce7 Series Graphics
• Support DirectX 9.0, Shader Model 3.0,
nView
• Programmable PureVideo HD Video
Processor
LAN
• Onboard Gigabit LAN
Audio
• Onboard 7.1-CH HD Audio CODEC
• Supports auto jack sensing and S/PDIF
Out
Serial ATA
• 4x SATA 3Gb/s supports SATA RAID 0,
1, 0+1, 5, and JBOD
Expansion Slots
• 1x PCI-E X16 slot
• 1x PCI-E X1 slot
• 2x PCI slots
Internal I/O Connectors
• 1x Floppy port
• 1x Ultra ATA 133 IDE connector
• 4x SATA 3Gb/s connectors
• 3x USB 2.0 headers
• 1x FP-Audio header
• 1x CD-In connector
Rear Panel I/O
• 1x PS/2 Keyboard connector
• 1x PS/2 Mouse connector
• 1x Optical S/PDIF Out connector
• 1x D-Sub connector
• 1x DVI connector
• 1x 7.1-CH Audio connector
• 4x USB 2.0 connectors
• 1x RJ-45 Gigabit LAN connector
abit Engineered
• abit Softmenu
™
Technology
RoHS
• 100% Lead-free process and RoHS
compliant
Miscellaneous
• Micro ATX form factor (244mm x
244mm)
• Vista HW Ready
※ Specifications and information contained herein are subject to change without
notice.
