32
Over
Temperature
Normal Mode :Transfer to Bypass Mode
Battery Mode : UPS shuts down immediately.
Dimensions
(HxWxD in mm)
236 × 144 × 367 322 × 151 × 444 322 × 189 × 444
Physical
Weight 10kg 16.5kg 22.5kg
Operating
Temperature
0-40℃
Noise Level
＜50 dBA
Environmental
Relative Humidity 0-90% (without condensation)
Interface Type RS-232 port + USB (optional) + EPO (optional)
Slots Dry contact, 2
nd
R-232, 2
nd
USB, SNMP/Web Card
Interface
Compatible
Platforms
Microsoft Windows series, Linux, etc.
Safety IEC/EN 62040-1-1
EMC
IEC/EN 62040-2 class A, IEC/EN 61000-4-2/-3/-4/-5/-6/-8,
IEC/EN 61000-2-2, IEC/EN 61000-3-2/-3
Standards and
Certifications
Markings CE
* The UPS communication software may be downloaded from the Ablerex Web site at:
http://www.ablerex.com.tw/tw/htm/support-sl.htm
