9. Specifications
MODEL ITEM 1K 2K 3K
CAPACITY VA / W 1000 VA/700 W 2000 VA/1400 W 3000 VA/2100 W
Voltage Rating
110/140/160-300 VAC (Based on load percentage
0-25% / 25-50% / 50-100%)
Frequency Rating 45-65 Hz
Phase Single phase with ground
Power Factor 0.≧ 98 (with full linear load)
Generator Input Supported
INPUT
Input Connection 10 A, IEC 320-C14 10 A, IEC 320-C14 16 A, IEC 320-C20
Voltage 230 V, adjustable to 200/208/220/230/240
Voltage
Regulation
within ±1% until low-battery warning
Frequency
(Synchronized
Range)
3 Hz or 1 Hz (selectable)
Frequency
(Battery Mode)
50/60 Hz ±0.1% unless synchronized to line
Current Crest
Ratio
3:1
Harmonic
Distortion
< 3% at full linear load
< 7% at full non-linear load
Output Waveform Pure sine wave
Outlets
(3)
10 A, IEC 320-C13
(6)
10 A, IEC 320-C13
(6)
10A, IEC 320-C13
Line
mode
＜105％ continuous
106-120％ for 30 seconds transfer to bypass
121-150％ for 10 seconds transfer to bypass
＞150％ Immediately transfer to bypass.
Buzzer continuously alarms.
Battery
mode
＜105％ continuous
106-120％ for 30 seconds shuts down
121-150％ for 10 seconds shuts down
＞150％ Immediately shuts down.
Buzzer continuously alarms.
Output
Overload
capacity
Bypass
mode
＜105％ continuous
106-120％ for 250 seconds shuts down
121-130％ for 125 seconds shuts down
131-135％ for 50 seconds shuts down
136-145％ for 20 seconds shuts down
146-148％ for 5 seconds shuts down
149-157％ for 2 seconds shuts down
158-176％ for 1 seconds shuts down
177-187％ for 0.32 seconds shuts down
＞188％ for 0.16 seconds shuts down.
Buzzer continuously alarms.
31
Line mode 90% 90% 90%
Battery mode 85% 85% 85%
Efficiency
ECO mode 96% 96% 96%
Number of
batteries
2 4 6
Battery type 12 V/7.2 Ah Sealed, non-spillage, maintenance-free, lead acid
Rated Battery
Voltage
24 VDC 48 VDC 72 VDC
Backup time (half
load)
> 10 min. > 10 min. > 10 min.
Backup time (full
load)
> 3 min. > 3 min. > 3 min.
Standard 2.2 A 1.4 A 1 A
Charge
Current
(Max.)
External 8.8 A 11.2 A 8 A
Recharge time (to
90%)
3hr 3hr 3hr
Floating Mode
Charging Voltage
27.4Vdc±1％ 54.8Vdc±1％ 82.2Vdc±1％
Bluk Mode
Charging Voltage
30.0Vdc±1％ 60.0Vdc±1％ 90.0Vdc±1％
Battery
DC leakage
current
≤ 30 µA with no AC applied and the unit in the off position
AC to DC 0 ms
Transfer time
Inverter to Bypass 4 ms (Typical) 4 ms (Typical) / 0 ms (Optional)
DC start Yes
Self
Diagnostics
By panel button or software control
Standard
Load Level/Battery Level/ Battery Mode/ Normal Mode/Bypass
Mode/ Self-Test/ Weak/Bad Battery/Site Wiring Fault/ Fault/
Overload
LED
Optional Programmable Outlet1/ Programmable Outlet2
Front Panel
Button ON (Alarm Silence)/ OFF (Test/Level Button)
Battery Mode Sounds once every 1.5 seconds
Low Battery Sounds once every 0.2 seconds
Overload Sounds once every 3 seconds
Normal alarm Sounds once every 3 seconds
Audible Alarm
Fault Continuous tone
Short Circuit
Bypass mode : Fuse
Normal Mode : Output Breaker/Electronic Circuit
Battery Mode : Output Breaker/Electronic Circuit
Battery ABDM
Protection
EPO(Optional) UPS shuts down immediately.
