Abloy DA430 - Assembly of operator and standard arm DC190 to closing side

10
6.2 Assembly of the operator and standard arm DC190 to the
closing side
20**
42
Min. 21* Max. 32*
340
Ø 6
Hinge line
*The measure from bottom of the operator
** The measure from bottom of the frame
80
68
