COMMISSIONING
1 Check the free movement of the door.
2 Turn mode switch to MAN.
The mode switch is located in the head panel.
3 Plug in the mains and turn main switch on.
The main switch is located in the head panel.
4 Choose the type of the arm
The jumpers are located on the control board.
Jumper is connected.
Jumper is disconnected.
5 Check the DOOR
”Sealed” enables motorized closing pull before opening and fi nal pull when closing. Select
this to ensure the proper function of the lock when prepull and fi nal pull are needed.
Final pull will be activated 20 - 30 mm before the doors closed position. Final pull is
activated 1 second, when door is closed position.
When hold closed jumper is selected, operator pushes the door against the frame.
Push&Go is in operation, when mode switch is in AUTO position. When door is pushed or
pulled manually operator opens the door. Operator opens the door to adjusted opening
angle and closes the door after 3 second hold open time.
Note! It is not possble to use Push&Go and free swing options at the same time.
ARM
standard
sliding
sealed
hold closed
Push&Go
DOOR
sealed
hold closed
Push&Go
DOOR
sealed
hold closed
Push&Go
DOOR
Main switch Mode switch
