Absen A27 Plus Series - Cabinet Introduction; Product Component Drawing

- 9 - A27 Plus Series User Manual
2.1 Cabinet Introduction
Note:
Side locking screws are used to connect the cabinets while adjusting the gaps between the cabinets to
ensure the flatness.
2.2 Product Component Drawing
2.2.1 Mounting frame: used for wall mounting, including single and double frames.
Handle
Upper and lower side locking screw
Left and right locking screw
1X1 Single frame
1X2 Double frame
