Absen JP Series User Manual

Product Specifications
Parameters
JP6.25
JP8.33
JP9.37
Physical
Parameters
Pixels
SMD1515
SMD1921
SMD1515
Pixel Pitch (mm)
6.25
8.33
9.37
Cabinet Pixels
96×96
60×60
64×128
Pixel Density (Pixels / m
2
)
25600
7200
11377
Module size (L × W)/(mm)
600×200
500×125
600×150
Panel size (L × W × H)/(mm)
600×600×100
600×1200×100
500×1000×100
600×1200×100
Cabinet Material
Aluminum Profile + Die Casting Aluminum
Cabinet Weight (㎏/Cabinet)
5.5/8.1
6.5
6.5
Electronic
Parameters
Color Processing Depth (Bit)
14
14
14
Grayscale
16384
16384
16384
Refresh Rate (Hz)
3840
3840
3840
Drive Mode
1/3
1/3
1/4
Picture Frame Frequency
(Hz)
50/60
50/60
50/60
Signal Transmission
Distance (m)
UTP cable:＜
100 m;
Single-mode
fiber:＜10 km
UTP cable:＜
100 m;
Single-mode
fiber:＜10 km
UTP cable:＜
100 m;
Single-mode
fiber:＜10 km
Optical
Parameters
Brightness (nit)
4500
5000
3000
Horizontal Viewing Angle (°)
120
140
140
Vertical Viewing Angle (°)
110
140
120
Electrical
Parameters
AC Input Voltage (V)
100~240
100~240
100~240
AC Input Frequency (Hz)
50/60
50/60
50/60
Power Consumption
(Max./Avg)(W/m
2
)
750/250
660/220
375/125
Environmental
Parameters
Storage Temperature (˚C)
- 40~+60
- 40~+60
- 40~+60
Working Temperature (˚C)
- 20~+50
- 20~+50
- 20~+50
Storage Temperature (RH)
10%~90%
Non-condensing
10%~90%
Non-condensing
10%~90%
Non-condensing
Working Humidity (RH)
10%~90%
Non-condensing
10%~90%
Non-condensing
10%~90%
Non-condensing
Ingress Protection
IP65/IP54
Product Life (hrs)
100000
100000
100000
Leasing Product
Installation
Cabinet Installation Method
Rigging
Rigging
Rigging
Maximum number of hoisted
cabinets
16
16
16

Absen JP Series Specifications
