Absen K Plus Series - Page 12

12
Modular structure: Magnetic modules. Modules can also be rotated by 90 degrees
for installation. When rotating the module, the upper and lower four modules of the panel
are connected with a row of wires, and the four modules in the middle of the panel are
connected with a row master block.
the upper
and lower four
modules
row master block
