*Note：Absen will provide the automatic trim pieces calculator base on your screen panel matrix.
Cables:
Data cables for vertical cascade：
Data cables for horizontal cascade：
Power cables for horizontal cascade：
Power cables for vertical cascade：There’s a built-in vertical power cable inside the panel
Power-In Cable： 10 meters long power cable(The official standard); Others specification(Optional)
Location
Trim pieces specs（9 types）
Left & Right
Double height
Top-left&Bottom-right， Bottom-left&Top-right，
Left&right middle
Triple height
Top-left&Bottom-right， Bottom-left&Top-right，
Left&right middle，left&right full height
Upper & Lower
Single width
Universal single trim piece
Double width
Universal double trim piece
