- 14 - PL Lite Series User Manual
Lock left and right
90° Corner locking (for cube cabinet):
Creating 90° Corner
3.1 Hanging Installation
3.1.1 Hanging bar Illustration
Used for rigging installation, including single, double hanging bar and 90 degree hanging
bar.
Remove the movable lock
on the splicing surface;
Two connection blocks are
required to secure the
connection of the two
corner cabinets
