- 28 - PL V2 Series User Manual
Check for Power Supply Short Circuit
After completing the cabinet wiring, please use a multimeter to check if there is any short circuit at the AC
input power supply (L / N / PE) and DC output terminal (VCC / GND). If there is a short circuit, please
carefully investigate the wirings. Make sure all wirings are normal, and only then connect power to
operate the unit.
All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd.
Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further
notice.
malfunctioning;
6. Re-add the multi-function card;
7. Replace the multi-function card;
8. Replace the sending card;
8
No full screen
display
1. Check whether the setting of the playback window is
normal;
2. Check the output resolution of the video processor;
3. Check the output window of the video processor;
