3. Connections and functions
3.1 Housing overview & connections
1: Lens
2: 3-axis braket
3: Junction box
4: Micro SD card slot (Micro SD card not pre-installed)
5: Connection for test monitor (BNC connection, CVBS)
6: Reset button
