103
English
System log (TXT log)
Custom message (TXT format)
Each medium that you create can only be linked with one event.
Assigning a medium twice results in the incorrect functioning of the video server.
If you wish to use the same media type for two events, you must create two separate media
types beforehand.
Snapshot
“Source” The recording can be made from video streams 1–4.
“Send pre-event image(s)” Number of snapshots before an event.
“Send post-event image(s)” Number of snapshots after an event.
“File name prefix” Enter a name that will prefix the snapshot file name.
“Add date and time suffix to file name” Adds the date and time to the snapshot so that you can more easily
distinguish between the file names of snapshots either in sequential or event-controlled operation. Example:
“video@20030102_030405.jpg” means that the JPEG picture was taken on January 2, 2003 at 03:04:05
(i.e., just after 3:04 am). If you omit this suffix, the file is updated with the name “video.jpg” on the external
FTP server according to the specified time interval.
The data name is structured as follows:
Prefix_YYYYMMDD_HHMMSS : ABUS_20091115_164501
Prefix: see file name prefix
Y: placeholder for year, YYYY = 2009
M: placeholder for month, MM = 11
D: placeholder for day, DD = 15
H: placeholder for hours, HH = 16
M: placeholder for minutes, MM = 45
S: placeholder for seconds, SS = 01
Video clip
“Source” The recording can be made from video streams 1-4.
“Pre-event recording” Pre-event recording interval in seconds (max. 9 seconds).
“Maximum duration” Maximum duration for each file (max. 10 seconds).
The video stream that is configured in “Audio and Video” under “Select caching stream” is
offered as a source.
1 9 7
8
6 5 4 3 2
Trigger
Pre-event images Post-event images
1 9 7
8
6 5 4 3 2
Pre-event memory Post-alarm memory
