5.2 Video
MJPEG
Status display for stream 1 or stream 2:
Configuration: Stream 1 or stream 2 can be configured here.
Resolution: Resolution currently set for stream 1 or stream 2.
Frame rate: Frame rate currently set for stream 1 or stream 2.
Quality: Quality settings for stream 1 or stream 2.
Setting for stream 1 or stream 2:
Edit: To edit stream 1 or 2, mark one of the two streams and press this button.
Region of Interest: Use this function to limit transmission of a stream to a certain region of the video
image. This has the advantage that the available bandwidth is only provided for the
required region of the picture.
Select a certain size for the
Resolution: Select a resolution for the MJPEG stream here.
Options: 1,920 x 1,080, 1,280 x 720
Frame rate: Select a frame rate for the MJPEG stream here.
Options: 1 ~ 25 frames / second
Quality: Image quality setting as a percentage
H.264 / MPEG-4
Status display for stream 1 or stream 2:
Configuration: Stream 1 or stream 2 can be configured here.
Resolution: Resolution currently set for stream 1 or stream 2.
Frame rate: Frame rate currently set for stream 1 or stream 2.
Bit rate type: CBR: Constant bit rate with a variable quality.
VBR: Variable bit rate with a constant quality.
CVBR: The camera will try to maintain a certain quality, however will also try not to
exceed a maximum bit rate.
Bit rate: Setting for the video bit rate. When the camera is integrated into recorder systems, the
bit rate 6 MBit/s should not be exceeded.
Quality: Image quality setting as a percentage
GOP: [Group of Pictures]: H.264 and MPEG-4 are differential image procedures. This value
indicates how often a full image is transmitted between the differential images.
Image settings
Brightness: Brightness of the video image.
Saturation: Saturation of the video image.
Contrast: Contrast of the video image.
Sharpness: Sets the sharpness of the video image. A higher sharpness value increases the noise
in the video image.
White Balance: Auto: The white balance is set automatically (range: 2,000– 9,500 K).
R-gain: Red value setting for manual white balance.
B-gain: Blue value setting for manual white balance.
Rotation: Flip: Vertical mirroring of video image.
Mirror: Horizontal mirroring of video image.
