108
Event server: Choose between an SD card and a network drive as the target server. It is necessary that
an SD card or network drive be configured in the camera.
Schedule
Always:
The event action is always executed without a time-based restriction.
Schedule:
Here a schedule that has already been configured can be selected for the event action.
Schedules are configured under the “Event / Schedule” item.
6.5.3 Switching input and switching output
The settings for the switching output and switching input are defined here.
Port:
Switching input or output
Normal:
Setting for the normal state of the port.
NO (normally open)
NC (normally closed)
Current status:
Open Circuit = Open
Closed Circuit = Closed
6.5.4 Motion detection
Name:
Name of the motion window
Show all areas:
Check this box to show all configured motion areas in the preview video image.
Threshold value:
Threshold value for triggering of a motion event
Sensitivity:
Sensitivity setting of the motion area
For setting of the motion detection, an indicator in the preview video shows the current values of the threshold
value and the current triggering value. This helps with the configuration of the threshold value and sensitivity.
Add:
Delete:
Remove a configured motion area. Before doing this, you need to select an entry
from the list of motion areas.
