Abus TVIP86900 - Description of Connections

76
5. Description of the connections
No Description
1 Camera cover
2 Screw to release cover
3 Photo sensor
4 Lens
5 IR LEDs
6 Microphone (only in TVIP83900)
7 Loudspeaker (only in TVIP83900)
No Description
8 Micro SD card slot
9 Reset button
10 RS485 connection (not used)
11 Audio input (TVIP83900 only)
12
Power supply 12 V DC
13 RJ45 connection
14 Alarm input and output (TVIP83900 only)
15 Audio output (TVIP83900 only)
