Abus TVVR45021 - Connections on the Rear of the Device

81
Connections on the rear of the device
Note
Pay attention to the overview on page 79.
No.
Name
Function
8
VIDEO OUT: BNC video output
BNC connector for video output for connecting a
monitor as an alternative to VGA-/HDMI output
(no. 18 / no. 19)
9
AUDIO OUT:
 BNC (TVVR35011) audio output
 (TVVR45021) cinch audio output
(synchronised with video output)
10
LINE IN:
 BNC (TVVR35011) audio input
 Cinch audio input (TVVR45021)
(is not recorded, only transmitted via net-
work)
11
RS-232:
 Serial port – no functionality
12
eSATA connection (TVVR45021 only)
 Serial connection for external SATA hard
disk drive
13
Mains power connection:
 100-240 VAC, 50-60 Hz (TVVR45021)
 12 VDC, 3A (TVVR35011)
14
Power switch
15
ALARM IN:
 RS485 connection for PTZ cameras
 Max. 16 alarm inputs / 4 alarm inputs
ALARM OUT:
Max. 4 relay outputs / 2 relay outputs
16
LAN:
 Ethernet LAN connection
17
USB:
 USB Connector
18
HDMI:
 HDMI monitor connection
19
VGA:
 VGA monitor connection (9-pin), video output
signal
