AC Infinity SMART OUTLET - Controller Programming; Controller 76 Button Functions; Outlet Status Indicator

11
1. MODE BUTTON
Cycles through each of the controller’s mode: OFF, ON, AUTO (4 triggers), TIMER TO ON, TIMER
TO OFF, CYCLE (On and Off), and SCHEDULE (On and Off).
3. SETTING BUTTON
Cycles through each of the controller’s settings: DISPLAY BRIGHTNESS, °F/ °C, CLOCK,
CALIBRATION (Temperature and Humidity), and BUFFER (Temperature and Humidity).
2. UP/DOWN BUTTONS
Adjusts the value of your current mode. The up button increases and down button decreases the
setting. Hold both to reset values to OFF or 0.
4. OUTLET STATUS
Displays the outlet controller’s power status, indicating whether or not electricity is being fed to your
device. ON will display if your devices are being powered and OFF will display if your devices are
not being powered.
ON
TO
ON
TIMER TO
PM
1
2
3
5
6
7
8
9
10
4
11
PROGRAMMING
CONTROLLER 76
