FORD KUGA
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
2.5T
2008
÷
2012
„B”
21
blue-yellow
ECM location
„A”
89
white-blue
View of the pins in the connector of the petrol controller.
