Petrol ECM harness
Installation notes
Conn
ector
Pin No.
Wire colour
Signal
2.5
3.0
4.0
4.2
2006
FH300
020
biało-czerwony
Fuel pump control signal
ECM location
PI300
071
niebieski
Fuel pressure sensor signal
View of the pins in the connector of the petrol controller.
LAND ROVER SUPERCHARGED
Engi
ne
Year of
manufac
ture
Petrol ECM harness
Installation notes
Conne
ctor
Pin
No.
Wire colour
Signal
4.2
2007
B
20
green-orange
Fuel pump control signal
ECM location
A
71
blue
Fuel pressure sensor signal
