8.10.1 Management command bytes
Byte
Command/Value
Comments
0
[0x0D]
Command byte
1–63
[0x00]
Unused bytes, set to [0x00]
8.10.2 Management response bytes
Byte
Response/Value
Comments
0
[0x0D]
Command echoed
1
Media type value
See Table 21
2
Number of valid bytes to follow
Specifies the number of bytes in the
serial number
3–xx
Media serial number
Most significant bit first
xx–63
Ignored (unused bytes)
8.10.3 Example
This command retrieves the serial number from the media. The detected media type is MIFARE
Ultralight.
USB
Command:
[0x0D]
Response:
[0x0D][0x05][0x07][0x04][0xBC][0xB8][0xD2][0x3B][0x3C][0x80]
Serial
Command:
[0x6F][0x01][0x00][0x00][0x00][0xFF][0x00][0x00][0x00][0x00]
[0x0D]
Response:
[0x80][0x36][0x00][0x00][0x00][0xFF][0x00][0x00][0x00][0x00]
[0x0D][0x05][0x07][0x04][0xBC][0xB8][0xD2][0x3B][0x3C][0x80]
8.10.4 Media type values
The value of byte 2 indicates the media type as shown in the following table.
Table 21. Media type values for supported (and non-supported) media types
Media type
Type value
Current support
No media present
[0x00]
Yes
ISO14443-4 A
[0x01]
Yes
ISO14443-4 B
[0x02]
Yes
MIFARE Classic 1K
[0x03]
Yes
MIFARE Classic 4K
[0x04]
Yes
MIFARE Ultralight
[0x05]
Yes
MIFARE Plus
[0x06]
Yes
Felica media
[0x07]
No
