Accu-Chek Aviva Nano Reference Manual

Taking an Alternative Site Blood Sample
1. Place your thumb to the
side of the notch and
remove the cap by pulling
it straight off. It is not a
twist cap.
2. Align the notch on the
converter cap with the
notch on the finger
pricker and slide the cap
on until it stops.
3. Dial the depth setting to
5 ½ for forearm, upper
arm, thigh or calf testing.
Dial the depth setting to
3 for palm testing.
91

Accu-Chek Aviva Nano Specifications

General

Blood Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Measuring Range	10-600 mg/dL
Battery	1 x 3V CR2032 lithium battery
Storage Conditions	-25°C to 70°C
Memory	500 test results
Weight	Approx. 40 g (with battery)
