Accu-Chek Aviva Plus User Manual

17
The ACCU-CHEK Softclix Lancing Device
3
Using the ACCU-CHEK Softclix Lancing Device
• The black cap is for fingertip testing only.
• Remove the cap by pulling it straight o. Do not twist the cap.
• The AST cap* is for testing other approved sites on the body, not the fingertip.
• Remove the cap by pulling it straight o. Do not twist the cap.
• The penetration depth indicator on the comfort dial shows the current depth
setting. The higher the number, the deeper the penetration. The best depth setting
is the lowest number that lets you get enough blood for a test. Try dierent depth
settings to find the one that is right for you.
• For soft skin, we suggest a depth setting of2. For thick skin, try a higher depth
setting.
• We suggest starting at a depth setting of 5½ for forearm or upper arm testing, and
a depth setting of3 for palm testing. Once you perform a successful blood glucose
test, you may want to find the lowest depth setting that provides enough blood
with the least amount of pain.
*Available upon request from the ACCU-CHEK Customer Care Service Center at 1-800-858-8072.
Chapter 3: The ACCU-CHEK Softclix Lancing Device
51801_07021933001.indb 17 5/7/14 8:52 AM

Accu-Chek Aviva Plus Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Dimensions	94 x 52 x 21 mm
Measuring Range	10-600 mg/dL
Display	LCD
Memory	500 results
Battery Type	CR2032
Battery Life	Approximately 1000 tests
Automatic Power Off	90 seconds after use
Weight	59 g with battery
