Accu-Chek Aviva Plus User Manual

7
Your New System
1
1. Power/Set Button
Turns meter on or o and sets options.
2. Display
Shows results, messages, and test results
stored in memory.
3. Right Arrow and Left Arrow Buttons
Press to enter memory, adjust settings, and
scroll through test results.
4. Test Strip Slot
Insert test strip here.
1
2
3
5. Battery Door
6. Infrared (IR) Window
Transfers data from meter to computer.
4
5
Chapter 1: Your New System
The ACCU-CHEK Aviva Meter
1
6
51801_07021933001.indb 7 5/7/14 8:52 AM

Accu-Chek Aviva Plus Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Dimensions	94 x 52 x 21 mm
Measuring Range	10-600 mg/dL
Display	LCD
Memory	500 results
Battery Type	CR2032
Battery Life	Approximately 1000 tests
Automatic Power Off	90 seconds after use
Weight	59 g with battery
