Accutron FlowTrax IS User Manual

11 | Page
1A Enter flow units:
A M/S B kcfm
C cfm D M**3/s
E fpm F usec
1B Linear Units:
A Meters
B Feet
1C Enter face to
face distance:
1D Enter baseline
distance:
1E Enter cross section
area:
1F Enter air flow
direction sense:
A Normal sign
B Reverse sign
1G Enter zero flow
cutoff:
1H Enter instrument
full scale:
1I Enter 4-20mA over
range mode:
A Saturate/Clipping
B Emit 3mA error
1J Obstruction/fault
timeout in minutes
(100 = disabled):
enter value 0-100
1K Enter 4-20mA mode:
A 4mA 0% 20mA 100%
B 4mA 100% 20mA 0%
C Split mode 12mA = 0
1L Enter moving
average (0-255):
enter value 0-255
2A Enter calibration
correction: (0 – 100)
2B Enter noise filter
level: (0 - 100)
2C Enter wave detection
low threshold: (0 - 100)
2D Enter wave detection
high threshold: (0 - 100)
2E Enter dynamic range
limiting factor: (0 - 1000)
2F Enter detection
Hysteresis length:
(0 – 1000)
Config
Advanced
2G Enter XDUC Gain:
A 0 B 1 C 2
D 4 E 8 F 16
G 32 H 64
2H Enter moving
average type:
A Start at 0
B First reading
2I Enter alternate
updates:
A Disabled
B Enabled
2J Enter Envelope mask
suppression: (0 – 1000)
2K Enter Master gain:
enter value 0-127
2Q Accutron/J Freq
Tolerance:
0.250
2R Accutron/J Minimum
Sig. Duration (ms):
0.200
2S Accutron/J Sampling
Period (ms):
300.000
4A Select diagnostic
output:
A Envelope detect
B Filter
4B Test current output:
enter value between
4-20
Diagnostics
2N Accutron/J Signal
Filter:
A – Disabled
B – Enabled
2O Accutron/J Diag
Mode:
A – Bounding Box
B – Crossing Indexes
2P Accutron/J Min
Amplitude:
175.000
Modbus
3A Enter Modbus
address:
enter value 1-247
3B Select Modbus
baud rate:
A 9600 B 38400
C 57600 D 115200
3C Select Modbus
parity:
A None B Odd
C Even
3D Select Modbus
Stop Bits:
A 1 stop bits
B 2 stop bits
3E Select Modbus
TX delay:
A 0ms B 50ms
C 100ms
Note: Clicking the left button will back out
of Config, Advanced, Modbus and Diag
Menus.
*New as of V.4.03.IS
*New as of V.4.03.IS
*New as of V.4.03.IS
*New as of V.4.03.IS
*New as of V.4.03.IS
*New as of V.4.03.IS
*New as of V.4.03.IS
Sheet 2 of 2
IS Menu Flowchart
