1.3 Accutron IS Series Specifications
Connections: Screw terminal Block Type
Transducers: 3 ½” (Dia.) X 9 1/8” (L)
Display Readout: 16 Characters LCD display.
Each digit is 0.57” (H) X 0.24” (W)
Power Supply: 12.6VDC intrinsically safe power supply
Power Consumption: < 3.3 watts
Input Power: 12.6VDC
Display Units: M/S, CFM, KCFM, M**3/S, FPM
Temperature range: -40° to +60° Celsius
Accuracy: 2% FS or ± 0.05 M/S (whichever is greater)
Output type: 4-20mA
Output modes: Normal, Reverse, or Split (used for bi-directional measurements)
Fault/Alarm Output: (Not available)
Sensor cables: 100 feet STD (sensor-to-box). Custom cables up to 500ft.
Connectors: Stainless Steel, with O-ring seals. IP68 rated.
Sensor Mounting: Industrial CATV pan and tilt mount (non-aluminum)
Tunnel sizes: Can accommodate a face-to-face distance of 70 feet.
Programming: User interface onboard using navigation buttons.
Max Airflow: 0 to 40 m/s and higher (essentially no practical upper limit)
Bi-directional
Enclosure Torque
Requirements: 4.5 nm (40 in-lb)
Power Supply port parameters (J1): Ui = 12.5V, Ii = 2.5A, Ci = 0uF, Li = 0uH
Isolated Modbus port parameters (J3): Ui = 5.88V, Ii = 3.25A / 0.5A thermal, Ci =0.3uF, Li = 0uH
Isolated 4-20mA Output port parameters (J2): Ui = 28V, Ii = 93mA / 106mA thermal, Ci = 1uF, Li = 5uH
