Acer A315-53G - Maintenance Flowchart

5-4 Service and Maintenance
Maintenance Flowchart
The flowchart in Figure 5-1. Maintenance Flow provides a graphic representation of the module
removal and installation sequences. It provides information on what components need to be
removed and installed during servicing.
Figure 5-1. Maintenance Flow
SSD Module
Thermal
Module
DC-IN Cable
HDD Cable
Fan Module
Speaker
WLAN Module
USB Board
Hall Sensor
Board
RTC Battery Touchpad
DIMM Module
HDD Door
HDD Module
HDD CarrierLower Case
Battery
RAM Door
Mainboard
LCD Module
