LCD Panel Specification
LCD Panel Model
Items Unit Specifications
Screen Diagonal [mm] 480 (19.0”)
Active Area [mm] 376.32 (H) x 301.06 (V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.294 (per one triad) x 0.294
Pixel Arrangement R.G.B. Vertical Stripe
White Luminance ( Center ) [cd/m2] 270 (center, Typ) @ 7mA
Contrast Ratio 550 : 1 (Typ)
Optical Response Time [ msec ] 8 ms(Typ, on/off)
Color Saturation 72% NTSC
Nominal Input Voltage VDD [Volt] +5.0 V
Weight [Grams] 2700 (Max)
Physical Size [mm] 396 (H) x 324 (V) x 18 (D) (Typ)
Support Color 16.2M colors (RGB 6-bit data+FRC data)
Temperature Range
Operating
Storage (Shipping)
[
0
C]
[
0
C]
0 to + 50
- 20 to + 60
TCO’03 compliance TCO’03 compliance
Surface Treatment Hard-coating (3H), Non-Glare treatment
RoHS RoHS Compliance
