Acer AL1917

13
Main Board Diagram
Panel Interface
(CN101)
TSUM16AK
(Include ADC, OSD)
(U401)
Flash Rom
(U402)
OSD Control
Interface
(Key pad)
D-Sub
Connector
(CN405)
EEPROM
(U403)
EEPROM
(U404)
R
G
B
Hsync
Vsync
RXD
TXD
DB15_SDA
DB15_SCL
EPR_SDA
EPR-SCL
