Main Board Layout
Label Part Number Description
U201 090G6093 1 HEAT SINK
U401 056G 562100 TSUM16AK
U702 056G 563 21 AP1084K33LA
U406 056G 643 5A MAX810 STRG
U404 056G1133 34 M24C02-WMN6TP
U403 056G1133 56 M24C16-WMN6TP
CN901 087G 501 32 S AC SOCKET
CN902 095G8014 12 42 HARNESS
CN102 033G8032 4C WAFER
CN101 033G803412D WAFER
