LCD Monitor General Specification
Items Description
Driving system TFT Color LCD
Panel
M190EN04 V5
Size 48 cm(19")
Pixel pitch
0.294 mm( H ) × 0.294 mm( V )
Brightness 270 cd /m2 (Typical)
Contrast 550:1 (Typical)
Viewable angle
140° (H) 135° (V)
LCD Panel
Response time 8 ms
Video R, G, B Analog Interface
H-Frequency 30 kHz – 80 kHz
Input
V-Frequency 55-75 Hz
Display Colors 16.2M Colors
Dot Clock 135 MHz
Max. Resolution
1280 × 1024 @75 Hz
Plug & Play VESA DDC2BTM
ON Mode ≤ 37W
EPA ENERGY STAR®
OFF Mode ≤ 1W
Input Connector D-Sub 15pin
Input Video Signal Analog : 0.7 Vp-p (standard), 75 OHM, Positive
Horizontal : 376.32 mm
Maximum Screen Size
Vertical : 301.056 mm
Power Source 100~264VAC,47~63 Hz
Operating Temp: 5° to 50°C
Storage Temp.: -20° to 65°C
Environmental Considerations
Operating Humidity: 10% to 85%
Dimensions
416(W)×429.4(H)×182(D)mm
Weight (N. W.) 4.8 kg
