System Housing 1-3
1.1.2 Rear Panel Features
Figure 1-2 Rear Panel Features
Table 1-2 Rear Panel Features
# Item Description
1 On/off switch Turns power on and off
2 Power cord socket Connects a power cord
3 External CRT port Connects an external monitor
4 Parallel port Connects a printer or other parallel device
5 Serial port Connect a serial mouse or other serial device
6 PS/2 keyboard port Connects a PS/2 keyboard
7 PS/2 mouse port Connects a PS/2 mouse
8 Speaker port Connects to speakers
9 Microphone port Connects a microphone
10 USB port 2 Connects a USB device
11 USB port 1 Connects a USB device
