Acer E6300 - Page 77

67
English
C. MHL Digital
Note 1: Functions vary depending on model definition.
Note 2: MHL 1080p 3D 24p frame packing is not supported.
1080i (Top and Bottom) 1920 x1080 50 (25) 28.1
1080i (Top and Bottom) 1920 x1080 60 (30) 33.8
1080p (Top and Bottom) 1920 x1080 24 27.0
1080p (Top and Bottom) 1920 x1080 50 56.3
1080p (Top and Bottom) 1920 x1080 60 67.5
720p (Side by Side (Half)) 1280 x 720 60 45.0
1080i (Side by Side (Half)) 1920 x1080 50 (25) 28.1
1080i (Side by Side (Half)) 1920 x1080 60 (30) 33.8
1080p (Side by Side (Half)) 1920 x1080 50 56.3
1080p (Side by Side (Half)) 1920 x1080 60 67.5
Graphic source monitor
range limits
Horizontal scan rate:
15k-100kHz
Vertical scan rate:
24-120 Hz
Max. pixel rate:
Analog:165MHz
Digital:165MHz
Modes Resolution
V.Frequency
[Hz]
H.Frequency
[KHz]
VGA 640x480 59.94/60 31.5
480i 720x480 (1440x480) 59.94/60 15.7
576i 720x576 (1440x576) 50(25) 15.6
480p 720x480 59.94/60 31.5
480p_2x 1440x480 59.94/60 31.5
576p 720x576 50 31.3
576p_2x 1440x576 50 31.3
720p 1280x720 59.94/60 45.0
720p 1280x720 50 37.5
1080i 1920x1080 60(30) 33.8
1080i 1920x1080 50(25) 28.1
1080p 1920x1080 23.97/24 27.0
1080p 1920x1080 25 28.1
1080p 1920x1080 29.97/30 33.8
Graphic source monitor
range limits
Horizontal scan rate: 15k-50 kHz
Vertical scan rate: 24-60 Hz
Max. pixel rate:
Digital: 75 MHz
