Acer G205H

- 22 -
9
Lock 5 screws on the
PCBA board with this
order.
Screw-driver
11
Lock one grounded
screws on the SPS board
with order.
Screw-driver
Make sure the wire
doesn’t walk across
the red area
12
Scan for fooling
PC
Card go with panel.
13
Fasten the LVDS to panel
and fix the Main-BKT to
CLM-F
The BKT must fixed
into the clip of the BZL
14
Stick three Al foils on the
right and under between
panel and Main-BTK
Only for the monitor
with LGD panel which
has two lamps
接地螺丝
2
1
4
3
5
