3
English
Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1
Control panel
6
Remote control receiver
2
Zoom ring
7
Tilt adjusting wheel
3
Focus ring
8
Elevator button
4
Zoom lens
9
Elevator foot
5
Lens cap
# Description # Description
1
PC analog signal input connector
(VGA IN 2)
13
Audio input connector (VGA IN 1/DVI-
D/HDMI signal)
2
PC analog signal/HDTV/component
video input connector (VGA IN 1)
14 USB connector
3
DVI input connector (for digital signal
with HDCP function)
15 RS232 connector
4 HDMI connector 16 Audio output connector
5 Top cover release button 17 SPDIF output connector
6
Kensington
TM
lock port
18 Power socket
7
2
1
6
8
3
9
5
6
4
20 21 22 23 2 3
9
24 4
6 8 10 11 12 13 14 15 16
17
18
19
51
7
