Acer PD726W Service Guide

Appendix 94
PH730 PD726
70.85A01G001 ASSY ENGINE MODULE PH730 70.83N01G001 ASSY ENGINE MODULE PD726
23.83F01G002 YM10 PROJECTION ZOOM LENS
WITH
23.80J01G001 DLP 0.7”XGA ZOOM PROJECTION
LENS
48.83FDMGD01 DMD 1280*768 PIXEL 0.65 WXGA 1 48.83N01G001 DMD 0.7 XGA 12° LVDS TYPE A
61.81C01G001 DMD HEATSINK EP758/PH730 61.83N21G001 DMD HEATSINK NO FAN PD726
51.85A03G001 DMD HEATSINK MYLAR FOR
PH730
51.83N37G001 DMD HEATSINK MYLAR FOR
PD726
52.89633G001 THERMAL PAD FOR DMD HEAT
SINK
52.83N15G001 FUJIPOLLY SARCON XR-Hj,
THERMAL PAD FOR DMD HEAT
SINK, K=14
61.85A05G001 ROD MASK BRACKET PH730 61.89617G001 ROD BRACKET AL 0.6t EP759/
PD726
51.81541G001 TAPE 3M J350 17*30mm
23.85A19G001 Color Wheel Φ48mm 7 segments
W30 Sleeve Bearing,YO
23.83N19G001 COLOR WHEEL Φ48mm R92/G83/
W110/B75 SLEEVE BEARING CW;
YO
61.85A02G001 ROD HOLDER SUS301 0.2t PH730 61.89620G001 ROD HOLDER SUS301 0.2t EP759/
PD726
23.85A17G002 HOLLOW ROD 6.2mm*4.0mm*31.3
mm(t1.1mm) ,UNAXIS
23.89617G002 HOLLOW ROD 6.2mm*4.6mm*31.3
mm(t1.1mm)
51.83N19G011 FOCUS RING PH730 51.83N19G001 FOCUS RING PD726
51.83N22G011 FOCUS RING COVER PH730 51.83N22G001 FOCUS RING COVER PD726
51.85A02G001 ZOOM RING PC+ABS PH730 51.83N18G001 ZOOM RING PD726
70.85A13G001 ASSY MAIN-BD MODULE PH730 70.83N23G001 ASSY MAIN-BD MODULE PD726
80.85A01G001 PCBA MAIN BD FOR PH730 80.83N01G001 PCBA MAIN BD FOR PD726
70.85A09G001 ASSY TOP COVER MODULE
PH730
70.83N09G001 ASSY TOP COVER MODULE
PD726
75.85A03G001 ASSY TOP COVER ASSM. PH730 75.83N03G001 ASSY TOP COVER PD726
51.83N02G002 LENS AREA COVER PC MN-3600H
PH
51.83N02G001 LENS AREA COVER PC MN-3600H
PD
51.83N03G011 KEYPAD MAIN BUTTON PC PH730 51.83N03G001 KEYPAD MAIN BUTTON PC PD726
51.83N04G011 KEYPAD MIDDLE BUTTON PC
PH730
51.83N04G001 KEYPAD MIDDLE BUTTON PC
PD726
51.83N07G002 LENSCAP ADJUST BUTTON PC
MN-36
51.83N07G001 LENSCAP ADJUST BUTTON PC
MN-36
51.83N23G011 KEYPAD RIGHT BUTTON PC
PH730
51.83N23G001 KEYPAD RIGHT BUTTON PC
PD726
51.83N23G012 KEYPAD LEFT BUTTON PC PH730 51.83N23G002 KEYPAD LEFT BUTTON PC PD726
61.83N02G002 MANUAL LENS CAP AL-HAIRLINE
PH
61.83N02G001 MANUAL LENS CAP AL-HAIRLINE
PD
III. The Different Parts PD726 / PH730
