27 Chapter 3
6. Remove Lamp Driver / Fan
No Procedure Photo
1 Remove Lamp Driver:
(1) Unscrew 4 screws
(2) Unscrew 2 screws and
unplug 3 connectors to
remove the Lamp Driver.
2 Remove Fan Module:
(1) Unscrew 2 screws to
remove the Fan Module.
(2) Unscrew 4 screws to
separate the Fan Module.
