Acer V193

56
Part list
No. Photo Part Name Description Part No.
1
BEZEL ASSY(V193) AV6901 ABS 94HB MBK94GP APAV690110I
2
Base Assy AV6905 ABS 94HB MBK94 GP APAV690500I
3
BACK COVER ASSY
(ANALOG) BACK
COVER ASSY
(DUAL)
AV5203 ABS 94HB MBK94 GP
APAV690300I
APAV690310I
APAV690320I
APAV690330I
4
BUTTON AV5731 MBK94 ABS 94HB GP FBAV573100I
6
STAND NECK
ASSY(AV698)
AV5715 ABS 94HB MBK94 GP APAV571520I
7
CHASSIS(DUAL
CHASSIS(ANALOG)
VP949+VL949 D-SUB GP
ECAV691100I
ECAV691110I
ECAV691120I
ECAV691130I
8
MYLAR(UPPER)
MYLAR(LOWER)
AV5743 FR700 T=0.43MM 94V0 GP
AV5744 FR700 R=0.43MM 94V0 GP
ELAV694300I
ELAV694400I
9
SOCKET MYLAR AV5742 FR700 T=0.43MM 94V0 GP ELAV574200I
10
PANEL BRACKET_L AV6921 SECC T=0.8MM GP ECAV692100I
11
PANEL BRACKET_R AV6922 SECC T=0.8MM GP ECAV692200I
12
CHASSIS SUPPORT AV6941 SECC T=0.8MM GP ECAV694100I
13
HINGE BREAKET
(AV698)
AV5732 SGECC T=0.8MM GP ECAV573210I
