Chapter 3 60

4. Disconnect the left (bottom in this image) touch sensor cable.

5. Disconnect the touchscreen board to mainboard cable.

6. Remove the two (2) screws.

Step Size Quantity Screw Type

Touchscreen Board M2.0*4 2
