Acer Z5700 Series - Removing the Home Button Board

73 Chapter 3
Removing the Home Button Board
1. See “Removing the Back Cover” on page 48
2. Disconnect the Home Button board cable.
3. Remove the one (1) screw from the Home Button Board
Step Size Quantity Screw Type
Home Button
Board
M2.5*4 1
