Acorn 80 Installation Manual

23
ACORN 80 Installation Manual
SECTION 8
Programming
IF ANY REPROGRAMMING IS REQUIRED WITHIN 150MM OF EITHER THE TOP OR BOTTOM
LIMITS, THE FINAL LIMIT MUST BE REPROGRAMMED AS WELL.
8.1.10 Amending The Program
The carriage can be stopped at any time during programming, and if a mistake is made the program can be
over written.
8.1.11 Programming Do’s & Don’ts
DO
1 Set the final limit striker in the correct position
2 Only program to the measurements stated in the manual
3 Only program in the down direction
4 Always program creep speed at both terminal stops
5 Ensure confirmation of reset indication on display
6 Do reprogram the final limit if you have reprogrammed within 150mm of the terminal limit
DO NOT
1 Do not move the top charge point after datum has been set
2 Do not alter the level calibration potentiometer before or after programming
