ACORN 80 Installation Manual
APPENDIX 1
Installation Checklist
Tick the relevant boxes when the checks have been completed.
RAIL
Check all legs are correctly positioned.
Check all leg - fixing screws are secure.
Check charge points are secure and undamaged.
SEAT
Check swivel mechanism working correctly (where applicable).
Remove seat and check that swivel pin securing screw is tight.
Check arms remain in upright position when folded.
CARRIAGE
Check carriage is not loose on the rail.
Check carriage runs freely without encountering obstructions.
Manually test the operation of the over-speed governor.
Test operation of all safety interlocks.
Remove carriage from rail and check condition of rollers. Replace as required.
Check all 5 P.S.E’s are working correctly.
Battery voltage satisfactory and record V =
Check D.C. charge voltage satisfactory and record V =
D.C. charge current satisfactory and record mA =
GENERAL
Check all warning and information labels are fitted where necessary.
Check operation of arm control device.
Check operation of call and sends.
Lift Serial Number
Other Work Required or Completed

Acorn 80 Specifications

General

Safety Features	seatbelt
Speed	0.15 m/s
Seat Type	Padded
Footrest	Flip-up
Foldable	Yes
Color Options	Beige
Power Supply	Battery powered (2 x 12V sealed lead acid batteries)
